They are independent of one another and can be used individually. When unchecked, both the length and width of each "row" will be random.
#Floor generator sketch up full
When checked, all full boards will be the length entered and all boards will be the width entered. Specific to the Wood pattern option is Fixed Length and Fixed Width. The Fixed Depth option when unchecked will vary the Gap Depth by 0.5 to 1.5 the value entered. The %offset only applies to the Brick and Tile pattern options and will only be displayed when one of them is selected. Texture size, when entered, allows you to specify the width and height of the texture applied to each pattern face. Random Imperfections "unlevels" each pattern face a random amount and about a random axis. Rotate Texture rotates the texture applied to each pattern face by 90, 180 or a random number of degrees. Random Position Texture moves the texture applied to each pattern face in a random direction. Select a pattern option, modify the size and options as desired then click on the face to which the pattern is to be applied. The plugin, when installed, will be found in Plugins>SDM Tools>Face Tool>FloorGenerator My attempt to satisfy a request for a plugin that will generate typical floor patterns. Due to the nature of this pattern, length and width are "tied" to one another so the maximum of length or width*count is kept and the other adjusted to match. For Hexagon, the greater of the length and width is used as the radius/length of side.Īdded Basket Weave pattern and fixed minor bug with 0 texture size. The longest edge is used.Īdded Hopscotch and Hexagon patterns. Several new patterns added including an irregular polygon pattern.Ĭhanged pattern selection from Radio Buttons to a Drop List.Īdded Align Texture to Edge option.
#Floor generator sketch up update
Input boxes update when changed and exited using Tab key. All drop lists and checkboxes automatically update when selection changes or clicked. If you have previously downloaded and used this plugin, I strongly recommend that you use the reset option when you run this version for the first time.Įliminated the Update button. Added "Seed" option to enable repeatable random results.įixed a couple of bugs dealing with align with edge and random imperfections. Latest version uploaded to the Plugin Store. Hopefully fixed the problem for those of you who insist on X'ing out of the WebDialog.Īdded Toolbar Icon and a new pattern or two. Random texture folder selectable and saved from session to sessionĬorrected Random Imperfection logic and added inputs for min and max values. Saves last pattern from session to session Option to create Pattern behind face if face represents finished floor or wall. Current Material taken from picked face if it has material applied.
